제품 상세 정보:
|
|
| 원래 장소: | 중국 |
|---|---|
| 브랜드 이름: | Glawall |
| 인증: | SGS, ISO 9001,UL, CE |
| 모델 번호: | 완전히 모듈 식 이중 유리 벽 |
| 문서: | 25mm.pdf |
|
결제 및 배송 조건:
|
|
| 최소 주문 수량: | 10 케케묵은 어머니 |
| 가격: | US$80.00 10 - 99 square meters |
| 포장 세부 사항: | 합판 |
| 배달 시간: | 20-25 일 |
| 지불 조건: | L/C, D/A, D/P, T/T, Western Union |
| 공급 능력: | 달 당 3000 평방 미터 |
|
상세 정보 |
|||
| 이점: | 경쟁가격, 좋은 서비스, 높은 전문가, 품질 보증 | Origi의 장소: | 광동, 중국 |
|---|---|---|---|
| 공장 인증: | 예 | 공장 지역,공장 면적: | 20000 평방 미터 |
| 재료: | 알루미늄 프레임, 음향 패널 | 방음: | 38-45db |
| 패널 두께: | 60, 90.108mm | 유리 유형: | 강한 강화 유리 |
| 통풍: | 기류 시스템 | 보증: | 2 년 |
| 강조하다: | 90mm aluminum partition wall,double glass modular partition,aluminum frame partition system |
||
제품 설명
| Advantage | Competitive price, good service, high professional, quality guarantee |
| Place of Origin | Guangdong, China |
| Factory Certification | Yes |
| Factory Area | 20000 square meter |
| Material | Aluminum Frame, Acoustic Panels |
| Soundproofing | 38-45dB |
| Panel Thickness | 60, 90, 108mm |
| Glass Type | Strong tempered glass |
| Ventilation | Airflow System |
| Warranty | 2 Years |
| Feature | Benefit |
|---|---|
| Pre-Assembled Double Glass Panels | Complete 5+5mm glass panels with integrated frame - no on-site assembly |
| Plug-and-Play Channels | Simple installation with top/side/bottom aluminum tracks |
| Tool-Free Connection | Patented click-lock system secures panels without tools |
| Fast Installation | 2-person team can install 20m² in under 3 hours |
| 42dB Soundproof Rating | 10mm air gap effectively blocks office noise |
| Thermal Insulation | Reduces HVAC costs by maintaining stable temperatures |
| Step | Action |
|---|---|
| Step 1 | Install aluminum tracks (ceiling/floor/sides) using laser level |
| Step 2 | Slide pre-assembled glass units into steel keel - no heavy lifting required |
| Step 3 | Snap decorative covers over joints for perfect alignment |
| Feature | Specification |
|---|---|
| Frame | 90mm powder-coated aluminum (20+ RAL colors) |
| Glass | 5+5mm tempered (clear/frosted/tinted options) |
| Acoustics | 42dB Rw (upgradable to 48dB with laminate) |
| Fire Rating | EI30-EI60 available |
| Max Height | 4m without additional support |
| For Contractors | For Clients |
|---|---|
| 70% faster installs = more projects per year | Immediate usability - No waiting for paint/drywall to cure |
| 50% less labor cost vs traditional systems | Adaptable layouts - Reconfigure teams without construction |
| No construction waste - LEED points achievable | Premium aesthetics - Sleek, modern appearance |
